Hikvision T7204U1TA4C Turbo HD Color Vu Kit with 4-Channel DVR 4 Outdoor Security Camera Kit

Brand:Hikvision

5/5

Condition:New

523.00$

In stock

Description



Hikvision T7204U1TA4C Turbo HD Color Vu Kit with 4-Channel DVR 4 Outdoor Camera Kit

This Hikvision Turbo HD Color Vu Kit features the Hikvision AcuSense 4-channel DVR with a preinstalled 1TB HDD, and four 5MP outdoor analog HD turret cameras with a 2.8mm lens. The DVR encodes up to 8MP resolution and offers HDMI and VGA video outputs. The turret cameras stream 2560 x 1440 resolution at 30 fps and 2960 x 1665 at 20 fps. They support night vision color recording from up to 66′ away.

Key Features:

  • Color Vu technology provides vivid and colorful images 24/7
  • Light alarm (white light)
  • Day and night switching
  • White balance modes include: auto, manual, outdoor, and global
  • Auto exposure modes include: digital WDR, BLC, HLC, global, and HLS
  • 2D-DNR
  • Functions include: brightness, contrast, mirror, defective pixel correction, sharpness, anti-banding, and smart light
  • PAL/NTSC signal systems

Camera Specification

Camera

Image Sensor

5MP CMOS

Signal System

PAL/NTSC

Resolution

2960 (H) × 1665 (V)





Frame Rate

TVI: 5MP
@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps
AHD: 5 MP@20fps, 4 MP@25fps/30fps

CVI: 4 MP@25fps/30fps

CVBS: PAL/NTSC

Min. Illumination

0.001 Lux @ (F1.0,
AGC ON), 0 Lux with white light

Shutter Time

PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s

Lens

2.8 mm fixed
focal lens

Field of View

2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°

Lens Mount

M12

Light Alarm

Solid Light Alarm
(White Light)

Day & Night

24/7 Color Imaging

WDR (Wide Dynamic Range)

Digital WDR

Angle Adjustment

Pan: 0° to 360°, Tilt:
0° to 75°, Rotation: 0° to 360°


White Light

Auto/Off

Image Mode

STD/HIGH-SAT/HIGHLIGHT

AGC

Yes

Day/Night Mode

Color

White Balance

Auto/Outdoor/Global/Manual

AE (Auto Exposure)
Mode

DWDR ,BLC,HLC, Global, HLS

Noise Reduction

2D DNR

Language

English

Function

Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding ,Smart

Light

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

Audio In

Built-in mic

General

Operating Conditions

-40°C to 60°C
(-40°F to 140°F),
Humidity: 90% or less (non-condensing)

Power Supply

12 VDC ± 25%,

*You are recommended to use one power adapter to supply the
power for one camera.

Consumption

Max. 2.5 W

Protection Level

IP67

Material

Metal

White Light Range

Up to 20 m

Communication

HIKVISION-C

Dimension

Φ 85.1 mm × 77.62
mm (Φ 3.35″ × 3.05″)

Weight

Approx. 328
g (0.72 lb.)

DVR Specification

Model

Motion Detection 2.0¹





Human/Vehicle Analysis

Deep
learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search
by object or event type
is supported;

Perimeter Protection¹

Human/Vehicle Analysis

Up to 4-ch

Recording

Video compression

H.265 Pro+/H.265 Pro/H.265/H.264+/H.264













Encoding resolution

Main stream:

8 MP@8
fps/5 MP@12 fps/3K@12 fps/4 MP@15
fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25

fps (P)/30 fps (N)

*: 8 MP@8 fps is only available for
channel 1, 8 MP Lite is only
available for channel
2 to channel 4.





Main stream:

8 MP@8 fps/5 MP@12 fps/3K@12 fps/ 4
MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

Sub-stream:

WD1/4CIF/CIF@25
fps (P)/30 fps
(N)

Video bitrate

32 Kbps to 10 Mbps

Dual stream

Support

Stream type

Video, Video &
Audio

Audio compression

G.711u

Audio bitrate

64 Kbps

Video and Audio







IP video input2

2-ch (up to 6-ch)



Enhanced IP mode on:

4-ch (up to 8-ch), each
up to 4 Mbps

4-ch (up to 12-ch)



Enhanced IP mode on:

8-ch (up to 16-ch), each up to 4 Mbps

Up to 8 MP resolution

Support
H.265+/H.265/H.264+/H.264 IP cameras



Analog video
input

4-ch

8-ch

BNC interface (1.0
Vp-p, 75 Ω), supporting coaxitron connection





HDTVI input

8 MP@15
fps, 5 MP@20 fps, 3K@20 fps, 4
MP@30 fps, 4 MP@25 fps, 3 MP@18 fps,
1080p30, 1080p@25

fps, 720p@60 fps, 720p@50 fps,

720p@30 fps, 720p@25 fps

8 MP@15
5 MP@20 fps, 3K@20 fps, 4 MP@30
fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30
1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps,

720p@25 fps



AHD input

5 MP@20 fps, 4
MP@25 fps, 4 MP@30
fps, 1080p@25 fps, 1080p@30 fps,

720p@25
fps, 720p@30 fps



HDCVI input

5 MP@20 fps , 4 MP@25
fps, 4 MP@30 fps,
1080p@25 fps, 1080p@30 fps,

720p@25 fps, 720p@30 fps

CVBS input

PAL/NTSC



CVBS output

1-ch, BNC (1.0
Vp-p, 75 Ω),

resolution: PAL: 704 × 576, NTSC: 704 × 480



VGA output

1-ch, 1920 × 1080/60Hz,

1280 ×
1024/60Hz,

1280 × 720/60Hz

1-ch, 1920 × 1080/60Hz,

1280 ×
1024/60Hz,

1280 × 720/60Hz





HDMI output



1-ch, 2K (2560 × 1440)/60Hz,

1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

1-ch, 4K (3840 × 2160)/30Hz,

2K (2560 × 1440)/60Hz,

1920 × 1080/60Hz,

1280 × 1024/60Hz,

1280 × 720/60Hz

Video output
mode

HDMI/VGA
simultaneous output



Audio input3

1-ch (up to 4-ch is optional), RCA (2.0

Vp-p, 1 KΩ)

1-ch (up to 8-ch is optional), RCA (2.0 Vp-

p, 1 KΩ)

4-ch via
coaxial cable

8-ch via coaxial cable

Audio output

1-ch, RCA (Linear, 1 KΩ)

Two-way audio

1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)

Synchronous playback

4-ch

8-ch

Network

Remote connections

32

64



Network protocols

TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnPâ„¢,

HTTPS, ONVIF



Network interface

1, RJ45 10/100
Mbps self-adaptive

Ethernet interface

1, RJ45 10/100/1000 Mbps self-adaptive

Ethernet interface

Wi-Fi

Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Auxiliary interface

SATA

1 SATA interface

Capacity

Up to 10 TB capacity for each disk

Serial interface

RS-485 (half-duplex)



USB interface

Front panel: 1 × USB 2.0

Rear panel:
1 × USB 2.0

Front panel: 1 × USB 2.0

Rear panel:
1 × USB 3.0

Alarm in/out3

N/A (optional to support)

General

Power supply

12 VDC, 1.5 A

12 VDC, 2 A

Consumption

(without HDD)



≤ 10 W



≤ 15 W

Working temperature

-10 °C to +55 °C (+14 °F to
+131 °F)

Working humidity

10% to 90%

Dimension (W × D × H)

315 × 242 × 45 mm (12.4
× 9.5 × 1.8 inch)

Weight (without HDD)

≤ 1.16 kg (2.6
lb)

≤ 2 kg (4.4 lb)
