Brand :Dahua

5/5

Condition :New

Out of stock

Guaranteed Safe Checkout

Description



Dahua Technology PFH610V IR All-aluminum shell design, IP67, IK10, PoE,14 inch Outdoor Vandal-proof Housing Security Accessory

The Dahua PFH610V is a 10-inch indoor monitor designed for use with Dahua’s video intercom systems. It features a capacitive touch screen display with a resolution of 1024×600, allowing users to easily view and interact with video feeds and access control features. The monitor supports two-way audio communication, allowing users to communicate with visitors or other occupants of the building. It also features a built-in speaker and microphone, as well as support for external audio devices. The PFH610V can be connected to a network via Ethernet or Wi-Fi, and supports remote access and control via a mobile app or web browser. Additionally, it can be integrated with Dahua’s video management software to provide seamless integration with other security systems.



Key Feature

14″ Vandal-proof Housing

>14” housing, provides all-weather protection for box cameras and lens;
>All-aluminum shell design, IP67, IK10, 14” housing with different function modules: Built-in heating and cooling system, windows adopt water-proof films, 0-100m IR, built-in PoE module and support remote control of IR light by RS485;
>Aesthetic design
buy dahua from authorized dealer.

Product Selector

Model PFH610V PFH610V-H PFH610V-H-POE PFH610V-IR PFH610V-IR-POE
General
Inside Dimension
(LxWxH)
255x90x83mm
(10.04”x3.54”x3.27”)
255x90x70.5mm(10.04”x3.54”x2.78”)
215x90x83mm(8.46”x3.54”x3.27”)
Window Dimension ɸ60mm(ɸ2.36”)
Operating Temperature Set
-30ºC ~+60ºC
(-22℉~+140℉)
-40ºC ~+60ºC(-40℉~+140℉)
Heater N/A  5±5 ºC /OFF: 15±5 ºC
 <+5ºC(+41℉)
/OFF: ≥+5ºC(+41℉)
IR Distance N/A 0~100m(0~328.08ft)
RS485 Control N/A Yes, use RS484 to control IR light
Power Supply DC12V, AC24V
(just for camera)
AC24V/3A POE+
AC24V/5A
POE+
Power Consumption
(without camera)
N/A 30W 12W 55W 12.5W
Environmental
Operating Temperature
-30ºC ~60ºC
(-22℉~+140℉)
-40ºC ~60ºC
(-40℉~+140℉)
Humidity <90% RH
Ingress Protection IP67
Vandal Resistance IK10
Corrosion Protection N/A
Construction
Material Aluminum(case)&PC(others)
Dimension(LxWxH) 404mmx164mmx132mm(15.91”x6.46”x5.2”)
Weight 2.5kg(5.51lb) 2.7kg(5.95lb) 3.0kg(6.61lb) 3.0kg(6.61lb) 3.2kg(7.05lb)
Others
Certification CE, FCC, ICES CE, FCC, UL, EAC, ICES CE, FCC CE, FCC, UL, EAC, ICES CE, FCC, ICES
