Description
Hanwha Vision PND-A6081RF Wisenet P Series 2MP POE+ IP52 IK10 IR Flush Mount Dome AI IP Security Camera 4.38~9.33mm Lens
Hanwha Vision PND-A6081RF Dome AI Camera
2MP IR Indoor Flush Mount Dome AI Camera
- 2MP resolution @120fps
- WDR (120dB)
- Simple focus
- Triple codec H.265/H.264/MJPEG
- WiseStream III compression technology
- extreme WDR
- USB port for easy installation
- true D/N
- Object detection and Attribute Extraction (Person, Face, Vehicle, License Plate)
- BestShot
- Compatible with Wisenet Retail Insight v2.0 for Business Intelligence
- POE+/12VDC
- TPM with FIPS 140-2 level 2
View More Products
visit our another site
Video
|
| Imaging Device |
1/2″ CMOS |
| Resolution |
1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360 |
| Max. Framerate |
H.265/H.264: Max. 60/50fps(60Hz/50Hz, AI analytics on), Max. 120/100fps(60Hz/50Hz, AI analytics off) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| NETD |
None |
| Pixel Size |
None |
| Min. Illumination |
Color: 0.007Lux(F1.3, 1/30sec, 30IRE) B/W : 0.0007Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on), 30/25fps Color: 0.014Lux(F1.3, 1/60sec, 30IRE) B/W : 0.0014Lux(F1.3, 1/60sec, 30IRE), 0Lux(IR LED on), 60/50fps Color: 0.028Lux(F1.3, 1/120sec,30IRE) B/W : 0.0028Lux(F1.3, 1/120sec, 30IRE), 0Lux(IR LED on), 120/100fps |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation USB: Micro USB Type B, 1280×720 for installation |
| Video Transmission Distance |
None |
Lens
|
| Focal Length (Zoom Ratio) |
4.38~9.33mm(2.13x) motorized varifocal |
| Max. Aperture Ratio |
F1.3(Wide)~F2.15(Tele) |
| Angular Field of View |
H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple focus |
| Lens Type |
P iris |
| Mount Type |
None |
| Optional Lens |
None |
Pan / Tilt / Rotate
|
| Pan / Tilt / Rotate Range |
0˚~360˚ / -45˚~85˚ / 0˚~355˚ |
Operational
|
| Camera Title |
Displayed up to 85 characters |
| Direction Indicator |
None |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
WiseNR Ⅱ(using AI engine) SSNRⅤ |
| Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
| Defog |
None |
| Motion Detection |
8ea, polygonal zones |
| Privacy Masking |
6ea, rectangle zones – Color: Gray/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Auto prefer shutter control based on AI engine |
| Digital PTZ |
None |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Classified object type: Person/Face/Vehicle/License plate Attributes: Person(Gender, Color and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type: car/bus/truck/motorcycle/bicycle and Color) Support BestShot per object Analytics events based on AI engine – Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit), Face mask detection, Social distancing detection, Slip&Fall detection Analytics events – Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear) Support WiseDetector for Adding custom objects *Some of the video analytics only works with people and vehicle detection |
| Business Intelligence |
People/Vehicle/Crowd counting, Queue management, Heatmap based on AI engine |
| Serial Interface |
None |
| Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
| Alarm Events |
When alarm trigger occurred – File upload(image): e-mail/FTP – Notification: e-mail – Recording: SD/SDHC/SDXC or NAS recording at event triggers – Alarm output – Handover: PTZ preset, send message by HTTP/HTTPS/TCP – Audio clip playback – MQTT: publication |
| Audio Streaming |
None |
| Audio In |
Selectable(mic in/line in) |
| Audio Out |
Line out |
| Light Type |
IR LED (850nm) |
| Light Viewable Length |
None |
| IR Viewable Length |
WiseIR 40m(131.23ft) |
Network
|
| Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine) |
| Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
| Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 6 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), MQTT |
| SIP support (VoIP, Peer-to-peer, SIP/PBX integration) |
None |
| Security |
None |
| Application Programming Interface |
ONVIF Profile S/G/T/M SUNAPI(HTTP API) Wisenet open platform – WiseAI application included(Analytic based on AI, Business intelligence) |
Security
|
| OS / Firmware Protect |
Encrypted Firmware, Secure boot, Signed Firmware |
| User authentication |
Digest Authenticaton, Prevent brute-force attack |
| Network authentication |
IEEE 802.1X (EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication |
HTTPS, WSS (WebSocket Secure) |
| Access Control |
IP-based access control |
| Data Protect |
Encryption Credentials, Encrypt compress for live recording file |
| Audit |
Access / System / Event Log management |
| Device ID |
Device certificate (Hanwha Techwin Root CA) |
| Secure Storage |
TPM, SDcard partition encrypt |
| Security Certificate |
TPM with FIPS 140-2 level 2 |
General
|
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
None |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot Max. 512GB(256GBx2) |
| Memory |
4096MB RAM, 512MB Flash |
Environmental & Electrical
|
| Operating Temperature / Humidity |
-25°C ~ +50°C (-13°F ~ +122°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP52, IK10, Plenum rate |
| Input Voltage |
PoE+(IEEE802.3at), 12VDC |
| Power Consumption |
PoE+: Max 19.50W, typical 16.00W 12VDC: Max 17.00W, typical 13.50W |
Mechanical
|
| Color / Material |
White / Aluminum, Hard-coated dome bubble |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
Ø205x163mm(8.07×4.92″), 1.95Kg(4.30lb) |
